Karnataka Metal Company

ACP Sheets & Panels

300+ Colours and Finishes. Ready Stock in Bangalore. Authorised Aludecor Distributor Since 2008.

50+ Years
In Aluminium Since 1974
300+
Colours and Textures
4 Fire Grades
NFR, FR, A2, AG+
Ready Stock
Bangalore Retail Outlet
ACP sheets stacked on edge showing the aluminium skins bonded to the core

Two aluminium skins bonded to a core, one of the lightest cladding materials at 3.5 to 5.6 kg/sqm. Four fire safety grades: NFR, FR, A2, and AG+. 300+ colours and finishes from ready stock. Read our complete ACP buying guide.

ACP Panel Categories We Supply

Aludecor ACP panels in four fire safety categories.

Interior wall panelling in PE core ACP, B2 fire classification
B2

Non-Fire Resistant (NFR / PE Core)

Signage, interior walls, shop boards, and low-rise structures. The most affordable ACP category.

Learn More
Commercial building facade clad in FR core ACP, B1 fire classification
B1

Fire Retardant (FR Core)

The standard for commercial facades, retail exteriors, and mid-rise projects. Mandatory for buildings above 15 metres per NBC 2016.

Learn More
High-rise facade clad in A2 non-combustible ACP panels, A2-s1,d0 classification
A2-s1,d0

Fire Proof (FR A2 Core)

Non-combustible grade for high-rises, hospitals, airports, and government buildings. Aludecor: first ACP manufacturer in India to achieve A2 certification.

Learn More
Clean room interior finished with AG plus anti-bacterial ACP panels
AG+

Anti-bacterial (AG+)

Silver-ion coated panels for healthcare facilities, laboratories, food processing units, and clean rooms. The AG+ coating actively inhibits bacterial growth on panel surfaces.

Learn More
Technical Data

ACP Sheet Specifications

Standard ACP Sheet Sizes
Size (mm) Size (ft approx.) Common Usage
1220 × 2440 4 × 8 ft Most common standard size
1220 × 3050 4 × 10 ft Medium-length facades
1220 × 3660 4 × 12 ft Large facade panels, high-rise cladding

Custom sizes are available on request from Aludecor.

ACP Sheet Thickness and Weight
Total Thickness Aluminium Skin Weight (approx.) Best For
3mm 0.21 to 0.25mm per side 3.5 to 3.8 kg/sqm Signage, interior walls, furniture
4mm 0.25mm or 0.50mm per side 5.5 to 5.6 kg/sqm Standard exterior and interior cladding

For exterior applications, always specify 0.50mm skin thickness for better wind load resistance, impact strength, and panel flatness.

Stack of Aludecor ACP sheets showing 4mm thickness and multiple colour finishes
ACP sheets stacked on edge — the aluminium skins and core of each panel.
Coating Types
Coating Film Thickness Outdoor Colour Retention Specify For
PE (Polyester) ~16 microns 5 to 10 years Interior only. Most manufacturers do not offer warranty on PE coatings.
PVDF (Polyvinylidene Fluoride) 25 to 35 microns 25 to 30+ years All exterior applications. Must contain minimum 70% PVDF resin (Kynar 500 certified). 10 to 15 years manufacturer warranty.
Installation Methods
Method How It Works Best For
Rout and Return (Cassette) V-groove routed on panel back, edges folded into a tray, hooked onto aluminium substructure with clip angles. All fixings concealed. All exterior facades, high-visibility projects. Preferred method to avail manufacturer warranty.
Direct Fix (Rivet/Screw) Panels cut to size, fastened directly to substructure using aluminium rivets or self-tapping screws through the panel face. Interior panelling, low-rise projects, signage.

For both methods, allow 10 to 15mm joint gaps between panels for thermal movement, sealed with neutral-cure silicone sealant.

ACP Sheet Pricing

ACP pricing depends on skin thickness (0.25mm vs 0.50mm), core type (PE, FR, A2), coating (PE vs PVDF), colour, and order quantity, and moves with market conditions. Contact us for current Aludecor pricing and project-specific quotations.

Finishes & Textures

ACP Sheet Colours and Finishes

Aludecor ACP panels are available in 300+ colours and textures across five finish categories, giving architects and designers full creative control over facade and interior aesthetics.

Solid Colours
Metallic
Wood Grain
Stone
Specialty
Aludecor ACP sheet colour samples showing solid, metallic, wood grain, and stone finishes
Finish Categories
Finish Category Examples Popular For
Solid Colours Ivory white, coffee brown, dark grey, burgundy, cream, full RAL spectrum Commercial facades, institutional buildings
Metallic Finishes Champagne gold, silver, bronze, copper, rose gold, brushed aluminium Corporate headquarters, premium retail
Wood Grain Finishes Oak, walnut, teak, cherry, mahogany Retail facades, restaurant interiors, residential elevations
Stone, Marble, and Sand White marble, travertine, granite effects, sand textures Contemporary facades, hospitality projects
Specialty Finishes Mirror, Granicia, Rugged Metal, Mason Mark, printable ACP Custom branding, signage, feature walls

Wooden ACP sheets replicate natural timber aesthetics without the weight, maintenance, or fire risk of real wood. All exterior finishes are available with PVDF coating for long-term colour retention.

Where ACP Is Used

ACP Sheet and Panel Applications

Aluminium cladding sheets are specified when projects require lightweight material (3.5 to 5.6 kg/sqm compared to 40+ kg/sqm for stone), large flat surfaces, rapid installation, or a wide range of finishes at competitive cost.

ACP cladding on a commercial office building facade in Bangalore

Commercial and Corporate Facades

Office buildings, IT parks, corporate headquarters, and retail spaces. FR and A2 grade panels with metallic or solid PVDF finishes.

ACP cladding on an airport terminal building in India

Infrastructure and Institutional

Airport terminals, railway stations, hospitals, and government buildings. A2 non-combustible grade panels specified for these occupancies.

ACP panel elevation on a residential tower in South India

Residential Elevations

High-rise towers, villas, and apartment entrances. PVDF-coated panels maintain consistent appearance for 25 to 30 years.

ACP sheet signage and shop front cladding for a retail store

Retail and Signage

Shop fronts, showroom facades, petrol station canopies, branded signage. 3mm PE-coated panels for signage; 4mm PVDF for retail exteriors.

ACP wall panelling and false ceiling in a modern office interior

Interior Applications

False ceilings, wall panelling, elevator interiors, column covers, reception areas, partition walls. PE-coated 3mm panels for most interior use.

For projects combining ACP cladding with glazing, Karnataka Metal Company can supply aluminium composite panels, toughened glass, and aluminium profiles together, reducing procurement timelines and ensuring material compatibility across the facade.

Our Clients

Trusted by Leading Organizations

By the Numbers

325
Clients Served
190,000+
Sq Ft Covered
5 Facilities
Across Bangalore
South India
Karnataka, Kerala, TN, Telangana, AP

Why Choose Karnataka Metal Company for ACP Sheets

Ready Stock in Bangalore

City-centre retail outlet with large stocks of ACP sheets. Immediate availability without waiting for factory dispatch. No order is too small.

Integrated Facade Supplier

One of the integrated glass and aluminium companies in South India. ACP cladding + tempered glass for glazing + aluminium sections for framing, all from a single source. Simplifies procurement and ensures material compatibility.

Over Five Decades in Aluminium

Founded in 1974. Over 50 years of experience in aluminium across South India. Multiple manufacturing facilities in Bangalore covering extrusion, glass processing, and surface finishing.

Technical Guidance on Fire Compliance

We help architects and builders select the correct fire grade for their building type, height, and occupancy classification. Specification support from material selection through to documentation.

Flexible on Order Sizes

From a single sheet for signage to bulk supply for multi-building projects. Same attention and pricing support regardless of order size.

ISO 9001 & 14001 and BIS/ISI Certified

TUV-certified ISO 9001:2015 and ISO 14001:2015. All Aludecor panels carry BIS certification per IS 17682:2021. In-house quality lab.

Authorised Aludecor Distributor Since 2008

Aludecor is India's largest ACP manufacturer with 200,000+ projects across 250+ cities, 10.08 million sqm annual capacity, 7 lamination lines, and 205-point quality testing. First ACP manufacturer in India to achieve FR A2 certification. Innovations include honeycomb core panels, AG+ anti-bacterial panels, zinc and copper composites, and printable ACP sheets. Read our complete Aludecor ACP guide

Get in Touch

Karnataka Metal Company can help with ACP sheet selection, fire safety grade guidance, colour consultation, bulk orders, and competitive pricing on Aludecor ACP panels.

ACP colour samples on display at the Karnataka Metal Company showroom in Bangalore
Address16 & 17, A.M Road, Kalasipalya Extension, Bangalore 560002
Contact Us →
Common Questions

Frequently Asked Questions

How long do ACP sheets last? +
PVDF-coated ACP sheets last 25 to 30+ years with proper installation. PE-coated panels last 5 to 10 years outdoors.
What is the standard ACP sheet size in India? +
The most common size is 1220 × 2440 mm (4 × 8 ft). Sizes up to 1220 × 3660 mm are also available.
What is the ACP sheet price per sq ft in India? +
ACP sheet prices depend on core type (PE, FR, A2), skin thickness, coating (PE vs PVDF), and colour, and move with market conditions. Contact us for a project-specific quotation.
What is the ACP sheet 8x4 price? +
The price of a standard 8x4 ft ACP sheet depends on core type and coating, and varies with current market rates. Contact us for current pricing.
Which ACP grade is required for high-rise buildings? +
Buildings above 15 metres require FR grade minimum (NBC 2016). Hospitals, airports, and government buildings need A2 non-combustible grade. All ACP panels must carry the ISI mark (IS 17682:2021).
What is the difference between 3mm and 4mm ACP sheets? +
3mm is for signage, interiors, and furniture. 4mm is the standard for all cladding. Always specify 0.50mm skin thickness for exterior facades.
What ACP sheet colours are available? +
Aludecor offers 300+ colours and textures across solid, metallic, wood grain, stone, and specialty finishes.
